| MODEL | Type | Unit Match or Number of Zones | Clg Cap MBtuH | SEER | Htg Cap MBtuH | HSPF | Refrigerant Connections | Dimensions HxWxD | Weight |
|---|---|---|---|---|---|---|---|---|---|
| DHPS09CSM42Q1 | Outdoor | DHPS09NWM42Q1 | 0.0 | 0.0 | 0.0 | 0.0 | 21.2x33.3x12.6 | 81 | |
| DHPS12CSM42Q1 | Outdoor | DHPS12NWM42Q1 | 0.0 | 0.0 | 0.0 | 0.0 | 23.2x33.3x12.6 | 89 | |
| DHPS18CSM42Q1 | Outdoor | DHPS18NWM42Q1 | 0.0 | 0.0 | 0.0 | 0.0 | 29.1x40.5x18.5 | 100 | |
| DHPS24CSM42Q1 | Outdoor | DHPS24NWM42Q1 | 0.0 | 0.0 | 0.0 | 0.0 | 31.1x38.6x16.8 | 132 | |
| DHPS09NWM42Q1 | Wall | DHPS09CSM42Q1 | 9.0 | 27.0 | 9.8 | 9.0 | 1/4-3/8 | 11x33.3x7 | 22 |
| DHPS12NWM42Q1 | Wall | DHPS12CSM42Q1 | 12.0 | 25.0 | 13.0 | 9.0 | 1/4-3/8 | 11x33.3x7 | 22 |
| DHPS18NWM42Q1 | Wall | DHPS18CSM42Q1 | 18.0 | 21.0 | 19.2 | 9.8 | 1/4-1/2 | 12x37x8 | 29 |
| DHPS24NWM42Q1 | Wall | DHPS24CSM42Q1 | 24.0 | 21.0 | 24.6 | 9.2 | 1/4-5/8 | 12.4x42.4x12.9 | 35 |
